Machine Tool Oil Skimming Equipment, Water Tank To Remove Floating Oil, Cutting Fluid Purification Equipment
Machine Tool Oil Skimming Equipment, Water Tank To Remove Floating Oil, Cutting Fluid Purification Equipmen
- Equipment parameters
| Equipment size | 650*400*800mm |
| Packaging box size | 750*450*900mm |
| Equipment weight | 49kg |
| water inlet | Φ16mm |
| Outlet pipe | Φ40mm |
| Oil outlet | Φ40mm |
| working voltage | AC220V |
| Power | 150W |
| Pre processing filtering accuracy | 0.3mm |
| Processing capacity | 1000 L/h |
| ozone value | 100-150mg/h |
2.Working principle of ozone value
The equipment consists of four systems: impurity filtration, air flotation device, ozone device, and oil-water separation;
1. Impurity filtration system: The filtration accuracy is 0.2UM, which can be customized according to customer needs. Impurities can be filtered in one go to meet usage requirements;
2. Air flotation device: The liquid filtered by the impurity filtration system enters the oil-water separation box and is accelerated to float small particulate matter and dispersed oil particles on the liquid surface through the air flotation device;
3. Ozone device: In the oil-water separation box, ozone gas is evenly mixed into the liquid through an air flotation device to achieve sterilization, disinfection, and deodorization, effectively preventing the cutting fluid from turning black and smelling;
4. Oil water separation device: The floating oil on the liquid surface is quickly separated through the air flotation device, achieving the effect of oil-water separation.
Cost benefit analysis:
1. Di'angtianke cutting fluid oil-water separator helps machining enterprises solve the problem of short service life and frequent replacement of cutting fluid due to bacterial and odorous growth;
2. Di Ang Tian Ke cutting fluid oil-water separator saves the operating costs of enterprises, including the cost of purchasing cutting fluid, waste liquid treatment cost, reducing machine tool failure rate, and reducing tool damage;
3. Remove mold, impurities, and other pollutants from the liquid tank to prevent the cutting fluid from deteriorating and smelling;
4. Purify the workshop environment, reduce worker allergies, and improve worker productivity.
